. Manual ORDER NO. CRT2497 GS300,430 AUDIO SYSTEM POWER AMPLIFIER VEHICLE DESTINATION PRODUCED AFTER TOYOTA PART No. PIONEER MODEL No. LEXUS GS300,430 USA,EUROPE August 2000 2 GM-8506ZT/E GM-8506ZT-91/E 2 GM-8606ZT/E GM-8606ZT-91/E Manufactured for TOYOTA CRT2497 by PIONEER CORPORATION PUB.
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 GM-8606ZT/E GM-8506ZT/E NOTE: - The GM-8506ZT-91/E and GM-8606ZT-91/E are supplementally genuine part for a TOYOTA vehicle, and a Pioneer product for recycling stock. As for the structure and electrical system, there is no difference between the GM-8506ZT-91/E, GM-8606ZT-91/E and GM-8506ZT/E, GM-8606ZT/E. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 2. EXPLODED VIEWS AND PARTS LIST 2.1 EXTERIOR (GM-8506ZT/E) NOTE: - Parts marked by “.”are generally unavailable because they are not in our Master Spare Parts List. ∇ mark on the product are used for disassembly.
Screws adjacent to - EXTERIOR SECTION PARTS LIST Mark No. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 2.2 EXTERIOR (GM-8606ZT/E) - EXTERIOR SECTION PARTS LIST Mark No.
Description Part No. Description Part No. 1 Screw BMZ30P060FMC 16 Screw(M3x6) CBA1393 2 Screw BMZ50P060FMC 17 Bracket CNC6807 3 Screw(M3x5) CBA1327 18 Holder CNC6808 4 Chassis CNA1852 19 Connector(CN901) CKM1222 5 Case.
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM DSP UNIT AMP UNIT. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 3.2 SCHEMATIC DIAGRAM Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS LIST”. 4.9V 4.9V Large size SCH diagram Guide page 5.0V Detailed page 2.3V 4.9V 4.9V 3.4V 4.9V 3.5V 3.5V 7.9V 3.0V. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 DSP UNIT 4.9V 4.3V 7.9V 7.9V 4.3V 4.3V 4.9V 2.5V 4.3V TAPE: -10.05dBs CD: -3.55dBs 2.5V 4.3V 5.0V 4.9V 4.9V 4.3V 4.3V 4.9V 4.3V 2.5V 4.9V 4.3V 4.3V 4.3V 4.9V 2.5V TAPE: +0.2dBs CD: +8.2dBs TUNER(EW): -7.8dBs TUNER(UC):-12.8dBs 13.2V 12.7V 13.2V 0.3mH. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 A-a B.
Toyota Factory Service Manual
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 A-b B.
Gm Factory Service Manual
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 4. PCB CONNECTION DIAGRAM 4.1 DSP UNIT NOTE FOR PCB DIAGRAMS 1.
The parts mounted on this PCB 2. Viewpoint of PCB diagrams include all necessary parts for several destination. Capacitor Connector For further information for SIDE A respective destinations, be sure to check with the schematic dia- gram. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 SIDE A CN905. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 DSP UNIT. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 SIDE B. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 4.2 AMP UNIT AMP UNIT CN51.
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 SIDE A CN52. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 AMP UNIT. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 SIDE B.
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 5. ELECTRICAL PARTS LIST NOTE: - Parts whose parts numbers are omitted are subject to being not supplied. The part numbers shown below indicate chip components. Chip Resistor RS1/SJ,RS1/SJ Chip Capacitor (except for CQS.) CKS., CCS., CSZS.Circuit Symbol and No.Part Name Part No. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 Circuit Symbol and No.Part Name Part No. Circuit Symbol and No.Part Name Part No. - - - - - (GM-8606ZT/E) RS1/10S473J RS1/10S472J RS1/10S102J RS1/10S682J RS1/10S102J RS1/10S103J RS1/10S102J RS1/10S154J RS1/10S473J RS1/10S472J RS1/10S104J RS1/10S473J RS1/10S473J RS1/10S392J RS1/10S102J RS1/10S103J RS1/10S473J RS1/10S102J RS1/10S473J RS1/10S473J RS1/10S393J.
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 Circuit Symbol and No.Part Name Part No. Circuit Symbol and No.Part Name Part No. - - - - - CKSQYB104K50 CEJA330M10 CKSQYB224K16 CEAL220M10 CEAL100M16 CEALNP100M10 CKSQYB103K50 CEALNP100M10 CKSQYB103K50 CKSQYB823K25 CEAL101M10 CEALNP220M16 CKSQYB104K50 CEALR68M50 CEALNP1R0M50 CEAL100M16 CEALNP1R0M50 CEJA470M10 CEALNP1R0M50 CEAL100M16 CEALNP1R0M50 CEALNP100M10. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 Circuit Symbol and No.Part Name Part No.
Circuit Symbol and No.Part Name Part No. - - - - - Diode UDZ20(B) RS1/10S620J Diode UDZ20(B) RS1/10S302J Diode UDZ20(B) RS1/10S302J Choke Coil 0.3mA CTH1079 RS1/10S1R0J RS1/10S1R0J RESISTORS RS1/10S473J RS1/10S153J RS1/10S104J RS1/10S153J RS1/8S222J RS1/10S333J. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 Circuit Symbol and No.Part Name Part No. Circuit Symbol and No.Part Name Part No. - - - - - CEJA100M16 CKSQYB102K50 CEJA2R2M50 CKSQYB102K50 CEANLR47M50 CKSQYB102K50 CEANLR47M50 CKSQYB102K50 CEANL4R7M50 CKSQYB102K50 CEANL4R7M50 CKSQYB102K50 CKSQYB102K50 CKSQYB102K50 CFTNA154J50 CFTNA154J50 CFTNA154J50 CFTNA154J50 CEAS221M16 1µF/50V CCH1296 1µF/50V. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 6.
ADJUSTMENT - Connection Diagram KEX-M8506ZT/UC KEX-M9506ZT/UC KEX-M8606ZT/EW Display KEX-M8706ZT/EW GGD1236 DSP AMP GM-8506ZT/E GM-8606ZT/E GGD1167 GGD1144 GGD1148 CD Changer CDX-M8076ZT/E. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 KEX-M8406ZT/UC KEX-M9406ZT/UC KEX-M9006ZT/EW KEX-M9106ZT/EW GGD1236 DSP AMP GM-8506ZT/E GM-8606ZT/E GGD1167 GGD1144 CD Changer GGD1148 CDX-M8076ZT/E CDX-M8106ZT/E. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 - Jig GGD1153. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 ASL SECTION Preset conditions 1. Set VR601 and VR602 around the center of the adjustable range. Ground pins 3 and 16 of IC601. Step Input Output Adjustment (MIC) (Pin 22) Adj.point Spec.
Conditions By using an oscillator, apply a sine Observe the output at VR602 1.2±0.3V. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 7.
GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 DISASSEMBLY Case Removing the Case(Fig.1) Heat Sink 1. Remove the Seal marked with arrows. Remove the seven screws A, seven screws B, and then remove the Case and Heat Sink. 1 Shield Removing the DSP Unit(Fig.2) 1. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 7.1.2 CONNECTOR FUNCTION DESCRIPTION SFL+ SFR+ SRL+ SRR+ TLMT GND SRR- SRL- N-MU SFL- SFR- CDR+ TXM+ CDL+ CDL- SGND CDMT CDR- TXM- MUTE SGND BUS+ BUS. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 7.2 IC PD2055A.
GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 - Pin Functions (PD5584B) Pin No. Pin Name Format Function and Operation ASLIN Difference of noise and signal input TLMT TEL mute input AVCIN AVC-LAN data input AVCOUT AVC-LAN data output AVCPW AVC-LAN driver power supply output DSPACK DSP-IC ACK input DSPCK DSP serial clock output DSPDT. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 7.3 EXPLANATION 7.3.1 OPERATIONAL FLOW CHART Reset Start-OFF -Power ON START Hard ware reset cancel TESTIN LOW input Test program check(Unit checker) - TESTIN HI/LOW input ASENS LOW input BSENS LOW input TESTIN HI input ASENS HI input BSENS HI input Unit checker program. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 - DSP error check (Normal) DSPERR1 DSPERR2 Both terminals confirmation every 4mS DSPCS1 DSPCS2 DSPCK 4mS interval (Periodical communication) DSPCS1 DSPCS2 DSPCK - Electronic volume refresh (Normal) Electronic VR IF About 500mS interval VCK1 VCK2 - DSP error check -Error continuation DSPRST About 1S interval. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 7.3.2 SYSTEM BLOCK DIAGRAM POWER SUPPLY(+B, ACC) SIGNAL(SOUND, VISION) - NAVIGATION SYSTEM(7SP) +B, ACC GM-8506ZT/E GM-8606ZT/E +B, ACC KEX-M8506ZT/UC KEX-M8606ZT/EW KEX-M8706ZT/EW VISION NAVIGATION (OTHER MAKERS) CDX-M8076ZT/E (OTHER MAKERS) CDX-M8176ZT/E +B, ACC - (7SP) +B, ACC GM-8506ZT/E GM-8606ZT/E +B, ACC KEX-M8406ZT/UC KEX-M9006ZT/EW KEX-M9106ZT/EW. GM-8506ZT,8506ZT-91,8606ZT,8606ZT-91 7.3.3 Service Mode For DSP Amplifier 1.
